STRUCTURE ELITE
Structural System: RCC Framed Structure designed for seismic compliant.
Masonry: 200mm for external walls & 100mm for internal walls.
Floor- Floor height (incl. slab): Shall be maintained at 2.95m.
ATT: Anti–termite treatment will be done.
WALL & CEILING FINISH-ELITE
Internal walls: Living, Dining, bedrooms, Kitchen, Utility & lobby finished with 2 coat of putty & 1 coat of primer & 2 coats of VOC less emulsion paint.
Ceiling: Finished with 2 coat of putty 1 coat of primer & 2 coats of VOC less emulsion paint.
Exterior walls: Exterior faces of the building finished with 1 coat of primer & 2 coats of VOC less Emulsion paint with color as per architect design.
Bathroom 1: Glazed/matte ceramic Tile of 300mm x 600mm will be finished up to false ceiling height & above false ceiling will be finished with a coat of VOC less primer.
Other Bathroom: Glazed/matte ceramic Tile of 300mm x 600mm will be finished up to false ceiling height & above false ceiling will be finished with a coat of VOC less primer.
Kitchen: Glazed/Matte Ceramic wall tile of size 600x 600mm for a height of 600mm above the counter top finished level.
Utility: Glazed/Matte ceramic wall tile of size 600x 600mm, height to match the kitchen wall tile.
Toilet ceiling: Grid type false ceiling.
FLOOR FINISH WITH SKIRITING -ELITE
Living, Dining: Vitrified tiles of size 600 x 1200 mm.
Bedrooms, Kitchen & Utility: Vitrified tiles of size 600 x 1200 mm.
Bathroom 1 tile: Anti-skid ceramic tiles of size 300x300mm.
Other Bathroom tile: Anti-skid ceramic tiles of size 300x300mm.
Balcony: Anti-skid ceramic tiles of size 300x300mm / wooden finish anti-skid tile.
Private open terrace (if applicable): Floors with pressed tiles finish/grass pavers.
KITCHEN & DINING-ELITE
Electrical point: For chimney & water purifier.
CP fitting: Jaguar/Roca OR equivalent.
Sink: Single bowl matte finished stainless steel sink (or) carysil (Quartz) sink with drain board (OR) equivalent with pull out sink faucet.
Drain: Pest free Square designer SS grating.
BALCONY-ELITE
Handrail: MS handrail as per architect’s design
Hanger: Cloth drying provision in one balcony.
Electrical point: One 5 amp point in recommended location.
BATHROOMS-ELITE
Sanitary fixture: Jaguar/Roca OR equivalent
CP fittings: Jaguar/Roca OR equivalent
Bedroom 1 – Bathroom: Wall mounted WC with cistern; Health faucet; single lever concealed diverter with Rain Shower & arm, Counter top wash basin with granite or quartz platform, glass shower partition (fixed).
Other Bathrooms: Wall mounted WC with cistern; Health faucet; single lever concealed diverter with overhead shower & arm, Wall mounted wash basin
Drain: Pest free Square designer SS grating and long trench grating (Master toilet) in bathing area.
JOINERY-ELITE
Main door:
Wide & fancy door of size 3’6” X 7’0” of good quality African teak wood frame with double side veneer finish and extended with an additional panel on one side.
Ironmongery like door lock of Digital lock system of Yale/Dorma OR equivalent, tower bolts, door viewer, safety latch, magnetic catcher.
Bedroom doors:
Good quality door frame with skin shutters of double panel for a height (7’0” ht.) 2100mm
Ironmongery like door lock of Godrej OR equivalent locks, thumb turn with key, door stopper, door bush, tower bolt etc.
Bathroom doors: Good quality door frame with FRP molded shutters of height (7’0” ht.) 2100mm with water proofing resistant on inner side.
WINDOWS-ELITE
Windows: UPVC windows with sliding/open-able shutter with see through plain glass.
French doors: UPVC frame and doors with toughened glass without grills.
Ventilators: UPVC frame of fixed OR adjustable louvered OR open able shutter for ODU access
ELECTRICAL POINTS-ELITE
Power Supply: 3 PHASE power supply connection.
Safety device: MCB; ELCB (Earth leakage Circuit breaker)
Switches & sockets: Modular box & modular switches & sockets of Anchor Roma / Schneider / equivalent
Wires: Fire Retardant Low Smoke (FRLS) copper wire of a quality IS brand Finolex / Polycab / Anchor Roma or equivalent
TV/ Telephone: Point in Living & Bedroom-1
Data: Point in Living room
Split- air conditioner: Point will be provided in Living & all bedrooms.
Exhaust fan: Point will be given in all bathrooms
Geyser: Geyser point will be provided in all bathrooms.
Back-up: 750W for 4BHK, 600 W for 3 BHK, 500W for 2BHK & 400W FOR 1 BHK.
Charging Pod: Mobile charging pod in Bedroom-1.
Occupancy Sensor: Occupancy sensor will be provided in Foyer (if any) and all toilets.
Air Purifier: Air purifier will be provided in the bedroom- 1 (PHILIPS OR equivalent)
Bluetooth Speaker: Blue tooth speaker will be provided in the kitchen.
STRUCTURE-SIGNATURE
Structural System: RCC Framed Structure designed for seismic compliant (Zone 3)
Masonry: 200mm for external walls & 100mm for internal walls
Floor- Floor height (incl. slab): Shall be maintained at 2.95m
ATT: Anti–termite treatment will be done
WALL & CEILING FINISH-SIGNATURE
Internal walls: Living, Dining, bedrooms, Kitchen, Utility & lobby finished with 2 coat of putty & 1 coat of primer & 2 coats of Emulsion (VOC less)
Ceiling: Finished with 2 coat of putty 1 coat of primer & 2 coats of Emulsion (VOC less)
Exterior walls: Exterior faces of the building finished with 1 coat of primer & 2 coats of Emulsion paint with color as per architect design (VOC less)
Bathroom 1 & 2: Glazed/matte ceramic Tile of 400mm x 800mm will be finished up to false ceiling height & above false ceiling will be finished with a coat of VOC less primer.
Bathroom 3 & 4: Glazed/matte ceramic Tile of 300mm x 600mm will be finished up to false ceiling height & above false ceiling will be finished with a coat of VOC less primer
Kitchen: Glazed/Matte Ceramic wall tile of size 600x 1200mm for a height of 600mm above 800mm from finished floor level.
Utility: Glazed/Matte ceramic wall tile of size 600x 1200mm, height to match the kitchen wall tile.
Toilet ceiling: Grid type false ceiling
WALL & CEILING FINISH-SIGNATURE
Foyer, Living, Dining: Vitrified tiles of size 600x1200mm
Bedrooms & Kitchen & Utility: Vitrified tiles of size 600x1200mm
Bathroom 1 & 2: Anti-skid ceramic tiles of size 400x400mm
Bathroom 3 & 4: Anti –skid ceramic tiles of size 300×300 mm
Balcony: Anti-skid ceramic tiles of size 300x300mm/ wooden tiles
Private open terrace (if applicable): Floors with pressed tiles finish/grass pavers.
KITCHEN & DINING
Electrical point: For chimney & water purifier
CP fitting: Kohler / American Standard OR equivalent
Sink: Single bowl matte finished stainless steel sink (or) carysil (Quartz) sink with drain board (OR) equivalent with pull out sink faucet.
Drain: Pest free Square designer SS grating.
Dining: Counter wash basin with polished granite/engineered marble or equivalent wherever applicable.
BALCONY-SIGNATURE
Handrail: MS handrail as per architect’s design
Hanger: Cloth drying provision in one balcony
Electrical point: One 5 amp point in recommended location.
BATHROOMS-SIGNATURE
Sanitary fixture: Kohler/American standard OR equivalent
CP fittings: Kohler/American standard OR equivalent
Master bathroom: Wall mounted WC with cistern; Health faucet; single lever concealed diverter with Rain Shower, hand shower/ bath tub; Counter top wash basin with engineered marble/ granite or quartz platform, glass shower partition.
Other Bathrooms: Wall mounted WC with cistern; Health faucet; single lever concealed diverter with overhead shower & arm, wash basin with polished granite/ engineered marble or quart platform, Glass shower partition.
Drain: Pest free Square designer SS grating.
JOINERY
Main door:
Wide & fancy door of size 3’6” X 7’0” of good quality African teak wood frame with double side veneer finish and extended with an additional panel on one side.
Ironmongery like door lock of Digital lock system of Hafele/YALE/DORMA OR equivalent, tower bolts, door viewer, safety latch, Magnetic catcher, door closure in SS finish
Bedroom doors:
Good quality door frame with laminated shutter of height (7’0” ht.) 2100mm
Ironmongery like door lock of Godrej OR equivalent locks, th
Bathroom doors:
Good quality door frame with design moulded skin door with water proofing on inner side of height (7’0” ht.) 2100mm.
Ironmongery like thumb turn lock of Godrej OR equivalent and a latch.
WINDOWS-SIGNATURE
Windows: UPVC windows with sliding/open-able shutter with see through plain glass without grills.
French doors: UPVC frame and doors with toughened glass without grills.
Ventilators: UPVC frame of fixed OR adjustable louvered OR open able shutter for ODU access.
ELECTRICAL POINTS-SIGNATURE
Power Supply: 3 PHASE power supply connection.
Safety device: MCB; ELCB (Earth leakage Circuit breaker)
Switches & sockets: Modular box & modular switches & sockets of Anchor Roma / Schneider / equivalent
Wires: Fire Retardant Low Smoke (FRLS) copper wire of a quality IS brand Finolex / Polycab / equivalent
TV/ Telephone: Point in Living & Bedroom 1
Data: Point in Living room
Split- air conditioner: Point will be provided in all bedrooms & living and dining.
Exhaust fan: Point will be given in all bathrooms
Geyser: Geyser point will be provided in all bathrooms
Back-up: 750W for 4BHK, 600 W for 3 BHK
Charging Pod: Mobile charging pod in Bedroom 1 & living area
Occupancy Sensor: Occupancy sensor will be provided in Foyer and toilets.
Air Purifier: Air purifier will be provided in the bedroom- 1 (PHILIPS OR equivalent)
Bluetooth Speaker: Blue tooth speaker will be provided in the kitchen and Bedroom 1 bathroom.
COMMON FEATURES
Lift: Elevators of 13 passenger automatic lift will be provided with interior finish in every core
Back – up 100 % Power backup for common amenities such as lifts, Water pump, STP & selective common area lighting
Name board: Apartment owner name will be provided in ground floor.
Lift facia: Granite cladding / Wall finishes / wall tiles as lift facia in all floors
Lobby & Corridor: Ground & first floor lobby with granite/equivalent & typical floors with tile flooring
Staircase floor: Ground floor with granite flooring or equivalent & typical floors with tile/Kota stone flooring
Staircase handrail: MS handrail with enamel paint in all floors
Ground level Flooring: Grano or equivalent flooring.
Terrace floor: Floors with pressed tiles finish
Notice board: Digital Notice board in Ground level entrance lobby of every core.
GYM & Indoor play area: Oxygen infused gym and indoor play area.
COMMON OUTDOOR FEATURES
Water storage: UG sump with OHT along with WTP (min. requirement as per water test report)
Rain water harvest: Rain water harvesting site
STP: Centralized Sewage Treatment plant
Intercom: Intercom will be provided
Safety: CCTV surveillance cameras will be provided all round the building at pivotal locations in ground level.
Well defined driveway: Interlocking paver block/equivalent flooring with demarcated driveway as per landscape design intent.
Security: Security booth will be provided at the entrance with My Gate App
Compound wall: Building perimeter fenced by compound wall with entry gates for a height as per Architect/landscape design.
Landscape: Suitable landscape at appropriate places in the project
Driveway: Convex mirror & driveway lighting for safe turning in driveway
Facade: Façade & compound wall lighting in project as per architects design
Swimming pool: Chlorine free swimming pool.
Electric car charging cum car wash bays are provided.
Mosquito Magnet: Mosquito magnet will be provided in open landscape spaces.
