Casagrand Orlena in Thanisandra

STRUCTURE

Structural system: RCC framed structure designed for seismic compliant (Zone 2)

Masonry: 200mm for external walls & 100mm for internal walls

Floor-floor height (incl. slab): Will be maintained at 2950mm

ATT: Anti–termite treatment will be done

WALL FINISH

Internal walls: Finished with 2 coats of putty, 1 coat of primer & 2 coats of emulsion

Ceiling: Finished with 2 coats of putty, 1 coat of primer & 2 coats of emulsion

Exterior walls: Exterior faces of the building will be finished with 1 coat of primer & 2 coats of emulsion paint with colour as per architect’s design

Bathroom: Glazed ceramic tile up to false ceiling height of size 300x600mm & above false ceiling will be finished with a coat of primer

Kitchen: Ceramic wall tile of size 300x600mm for a height of 600mm above the counter top finished level

Utility: Ceramic wall tile of size 300x600mm as per architect’s design intent wherever applicable

Toilet ceiling: Grid type false ceiling

FLOOR FINISH

Foyer, living, dining, bedrooms & kitchen: Vitrified tiles of size 600x1200mm

Bathroom: Anti-skid ceramic tiles of size 300x300mm

Balcony / Utility: Anti-skid ceramic tiles of size 300x300mm

Private open terrace (if applicable): Pressed tiles finish

KITCHEN & DINING

Kitchen: Platform will be finished with granite slab at height of 800mm from the finished floor level

Electrical point: For chimney & water purifier

CP fitting: American Standard / Grohe / equivalent

Sink: Stainless steel sink without drain board

Utility: Stainless steel sink with drain board

Dining: Wall mount washbasin wherever applicable

BALCONY

Handrail: MS handrail as per architect’s design

BATHROOMS

Sanitary fixture: American Standard / Grohe / equivalent

CP fittings: American Standard / Grohe / equivalent

Bedroom-1 bathroom: Wall mounted WC with cistern, health faucet, single lever diverter, overhead shower with a polished granite slab counter top wash basin

Other bathrooms: Wall mounted WC with cistern, health faucet, single lever diverter, overhead shower with a wall hung wash basin

JOINERY

Good quality main door of size 1050x2100mm with double side veneer with polish finish and panel on one side

Ironmongeries like digital door lock of Yale / equivalent, tower bolts, door viewer, safety latch, door stopper, etc.

Skin moulded shutter of size 900x2100mm with paint finish

Ironmongeries like mortise lock of Godrej or equivalent, door stopper, door bush, tower bolt, etc.

FRP shutter of size 750x2100mm

Ironmongeries like thumb turn lock of Godrej / equivalent

WINDOWS

Windows: Aluminium powder coated windows with sliding shutter with see through plain glass

French doors: Aluminium powder coated frame and doors with toughened glass

Ventilators: Aluminium powder coated frame of fixed / adjustable louvered / open-able shutter for ODU access

ELECTRICAL POINTS

Power supply: 3-phase power supply connection

Safety device: MCB & ELCB (Earth Leakage Circuit Breaker)

Switches & sockets: Modular box & modular switches & sockets of Schneider/equivalent

Wires: Fire Retardant Low Smoke (FRLS) copper wire of a good quality IS brand

TV: Point in living & bed-1 and provision in other bedrooms

Telephone: Point in living & bed-1

Data: Point in living & bed-1

Split- air conditioner: Provision in living / dining and point in all bedrooms

Exhaust fan: Point will be given in all bathrooms

Geyser: Geyser point will be provided in all toilets

Back-up: 600W for 3 BHK, 500W for 2 BHK & 400 W for studio apartment

NOTE – Master Bedroom refers to Bedroom – 1

COMMON FEATURES

Lift: Elevators of 8 passenger lift will be provided as per requirement

Backup: 100% power backup for common amenities such as clubhouse, lifts, WTP, STP & selective common area lighting

Name board: Apartment owner name will be provided in ground floor

Lift fascia: Granite cladding / wall finishes / wall tiles as lift fascia in all floors as per design intent

Lobby: Granite flooring at ground level & tile flooring at other levels

Corridor: Tile flooring at all levels

Staircase floor: Tile flooring for staircase

Staircase handrail: MS handrail with enamel paint in all floors

Terrace floor: Pressed tile flooring

OUTDOOR FEATURES

Water storage: Centralised UG sump with WTP (min. requirement as per water test report)

Rainwater harvesting: Rainwater harvesting is done at the site

STP: Centralised Sewage Treatment plant is done

Intercom: Intercom will be provided

Safety: CCTV surveillance cameras will be provided all around the building at pivotal locations in ground level

Walkway: Walkway spaces well-defined as per landscape design intent

Security: Security booth will be provided at the entrance

Compound wall: Site perimeter fenced by compound wall with entry gates for a height of 1800mm as per design intent

Landscape: Suitable landscape at appropriate places in the project as per design intent

Driveway: Convex mirror for safe turning in driveway in/out
